Place of Origin: | China |
Brand Name: | ACCPCB |
Certification: | ISO, UL, SGS,TS16949 |
Model Number: | P11267 |
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Vacuum packing with desiccant |
Delivery Time: | 5-8DAS |
Payment Terms: | L/C / T/T / Western Union / Paypal |
Supply Ability: | 30000SQ.M/PER MONTH |
Base Material: | FR4TG150 | Count Layer: | 4layer |
---|---|---|---|
Copper Thickness: | 1.2 OZ In All Layer | Finish Board Thickness: | 1.20mm |
Solder Mask: | Green | Min. Line Spacing: | 0.1mm/4mil |
Min. Line Width: | 0.1mm | Surface Finishing: | OSP |
Service: | OEM | ||
High Light: | led bulb circuit board,custom led pcb |
Green Street Light LED Printed Circuit Board 4 Layer FR4 TG150 Base Material
Production description :
this board is 4 layer it is used on LED street light. we can accept PCB prototype,samll volum, middle and large volume. no MOQ request for new order.all of our PCB are met UL, TS 16949,ROHS, ISO etc. certification.
Key Specifications/Special Features:
Base material : | FR4 4layer |
Copper thickness : | 1 / 1 / 1 / 1 oz |
Board thickness : | 1.0mm |
Min. hole size : | 0. 25mm |
Min. line width : | 8 mils |
Min. line spacing : | 8 mils |
Surface finishing : | OSP |
Soldermask color : | white |
Board thickness tolerance : | ±10% |
Twist& wrap : | ≤ 0.5% |
Certificate : | RoHS, ISO 9001, UL |
Products Application:
1, Security monitor: Moible phone, PDA, GPS, caramer monitor etc;
2, Telecom Communication :wireless LAN card, XDSL router,Servers, Optical Device,Hard Drive etc;
3, Consumer Electronics: TV, DVD,Digital Caramer, air conditoner, Refrigerator,set-top box etc;
4, Vehicle Electronices: Car etc;
5, Industrial controls: Medical device ,UPS equipment, Control device etc;
6, Military & Defense : Military Weapons etc;
Technology Capability:
Item | Technical Parameters |
Layers | 1-28 Layers |
Inner Layer Min Trace/Space | 4/4 mil |
Out Layer Min Trace,Space | 4/4 mil |
Inner Layer Max Copper | 4 OZ |
Out Layer Max Copper | 4 OZ |
Inner Layer Min Copper | 1/3 oz |
Out Layer Min Copper | 1/3 oz |
Min hole size | 0.15 mm |
Max.board thickness | 6 mm |
Min.board thickness | 0.2mm |
Max.board size | 680*1200 mm |
PTH Tolerance | +/-0.075mm |
NPTH Tolerance | +/-0.05mm |
Countersink Tolerance | +/-0.15mm |
Board Thickness Tolerance | +/-10% |
Min BGA | 7mil |
Min SMT | 7*10 mil |
Solder mask bridge | 4 mil |
Solder mask color | White,black,blue,green,yellow,red,etc |
Legend color | White,black,yellow,gray,etc |
Surface finish | HAL,OSP, Immersion Ni/Au ,Imm silver/SN,ENIG |
Board materials | FR-4;high TG;HighCTI; halogen free; Aluminum Bsed PCB,high frequency(rogers,isola),copper -base PCB |
Impedance control | +/-10% |
Bow and twist | ≤0.5 |
FAQ:
1. How do ACCPCB ensure quality?
Our high quality standard is achieved with the following.
1.1 The process is strictly controlled under ISO 9001:2008 standards.
1.2 Extensive use of software in managing the production process
1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
1.4.Dedicated quality assurance team with failure case analysis process
2. What kinds of boards can ACCPCB process?
Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.
3. What data are needed for PCB production?
PCB Gerber files with RS-274-X format.
4. What’s the typical process flow for multi-layer PCB?
Material cutting → Inner dry film → inner etching → Inner AOI → Multi-bond→ Layer stack up Pressing → Drilling → PTH → Panel Plating → Outer Dry Film → Pattern Plating → Outer etching → Outer AOI → Solder Mask → Component Mark → Surface finish → Routing → E/T → Visual Inspection.
5. How many types of surface finish ACCPCB can do?
the leader has the full series of surface finish, such as: ENIG, OSP, LF-HASL, gold plating (soft/hard), immersion silver, Tin, silver plating, immersion tin plating, carbon ink and etc. .. OSP, ENIG, OSP + ENIG commonly used on the HDI, we usually recommend that you use a client or OSP OSP + ENIG if BGA PAD size less than 0.3 mm.
Application:
Widely used in stage, Industrila control,computer,consuming electronics,security,automotive,power electronics,medical,telecom etc.
Any further question, welcome to contact us by sending your inquiries
