Black Solder Mask ITEQ FR4 PWB Circuit Board For Wireless Lan Card

Product Details:

Place of Origin:	China
Brand Name:	ACCPCB
Certification:	ISO,SGS,TS16949
Model Number:	S10212

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	Negotiable
Packaging Details:	Vacuum packing
Delivery Time:	3-5days
Payment Terms:	T/T ,Western Union,Paypal
Supply Ability:	50000SQ.M/Per Month

Contact Now

Detailed Product Description

Material:	ITEQ FR4	Count:	10 Layer
Surface Finish:	Immersion Tin	Application:	Wireless Lan Card
Solder Mask:	Green,black, Yellow Etc.	Copper Thickness:	1oz All Layer
Min. Hole Size:	8 Mil/6 Mil	Min. Line Spacing:	4mil
Min. Line Width:	4mil	Service:	Customize
High Light:	ITEQ FR4 PWB Circuit Board , 8mil PCB Circuit Board , ITEQ FR4 PWB PCB

Black Solder Mask ITEQ FR4 PWB Circuit Board For Wireless Lan Card

Production description :

this board is black soldermask pcb and used on wireless lan card . we can accep PCB prototype,samll volum, middle and large volume. no MOQ request for new boards, for repeat order, just meet 3sq.m.

Key Specifications of single PCB board :

Production Types:	Rigid PCB
Layer :	10 Layer
Base Material :	ITEQ FR4
Copper Thickness :	1 oz
Board Thickness :	0.4mm
Min. Finish Hole Size :	8 mil (0.10mm)
Min. Line Width :	4 mil
Min. Line Spacing :	4 mil
Surface Finishing :	ENIG,OSP,HASL,Immersion Gold,Gold Plating
Drilling hole tolerance:	+/-3 mil ( 0.075mm )
Min Outline tolerance :	+/-4 mil ( 0.10mm )
Working panel size :	max:1200mmX600mm (47'' X24'')
Outline profile:	Punching, Routing , CNC routing + V-cut
Solder mask :	LPI Solder mask, Peelable mask
Solder Mask Color :	Blue, black,yellow, matte green
Certificate :	UL, CQC, TS16949, ISO14000, ROHS
Silkscreen color :	White
Twist and Bow :	no more than 0.75 %

PCB Flow Chart.pdf

Products Application:

1, Consumer Electronics: TV, DVD,Digital Caramer, air conditoner, Refrigerator,set-top box etc;

2, Security monitor: Moible phone, PDA, GPS, caramer monitor etc;

3, Telecom Communication :wireless LAN card, XDSL router,Servers, Optical Device,Hard Drive etc;

4, Industrial controls: Medical device ,UPS equipment, Control device etc;

5, Vehicle Electronices: Car etc;

6, Military & Defense : Military Weapons etc;

Technology Capability:

Item	Technical Parameters
Layers	1-28 Layers
Inner Layer Min Trace/Space	4/4 mil
Out Layer Min Trace,Space	4/4 mil
Inner Layer Max Copper	4 OZ
Out Layer Max Copper	4 OZ
Inner Layer Min Copper	1/3 oz
Out Layer Min Copper	1/3 oz
Min hole size	0.15 mm
Max.board thickness	6 mm
Min.board thickness	0.2mm
Max.board size	680*1200 mm
PTH Tolerance	+/-0.075mm
NPTH Tolerance	+/-0.05mm
Countersink Tolerance	+/-0.15mm
Board Thickness Tolerance	+/-10%
Min BGA	7mil
Min SMT	7*10 mil
Solder mask bridge	4 mil
Solder mask color	White,black,blue,green,yellow,red,etc
Legend color	White,black,yellow,gray,etc
Surface finish	HAL,OSP, Immersion Ni/Au ,Imm silver/SN,ENIG
Board materials	FR-4;high TG;HighCTI; halogen free; Aluminum Bsed PCB,high frequency(rogers,isola),copper -base PCB
Impedance control	+/-10%
Bow and twist	≤0.5
