KB FR4 Material Double Sided PWB Printed Wiring Board For Toy Car

KB FR4 Material Double Sided PWB Printed Wiring Board For Toy Car

KB FR4 Material Double Sided PWB Printed Wiring Board For Toy Car
KB FR4 Material Double Sided PWB Printed Wiring Board For Toy Car
KB FR4 Material Double Sided PWB Printed Wiring Board For Toy Car
Product Details:
Place of Origin: China
Brand Name: ACCPCB
Certification: ISO, UL, SGS,TS16949
Model Number: P1116162
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Price: Negotiable
Packaging Details: Vacuum packing with desiccant
Delivery Time: 10-12days
Payment Terms: L/C / T/T / Western Union / Paypal
Supply Ability: 30,000SQ.M/Per Month
Contact Now
Detailed Product Description
Material: KB FR4 Thickness: 1.60mm
Surface Finish: HAL Lead Free Layer: 2L
Copper Thicknes:: 0.5 0Z PCB Standard: IPC-A-610 D
Type: Customized PCB Min Holes Size: 5mil
Min. Line Width: 5mil Min Copper Thicness: 20um
Solder Mask Color: Green,yellow, Red, Black Etc. Application: Measuring Instrument
High Light:

Double Sided PWB Printed Wiring Board

,

0.5OZ PWB Printed Wiring Board

,

0.5OZ pcb pwb

KB FR4 Material Double Sided PWB Printed Wiring Board For Toy Car





Production description :



this board is 2layer for toy car. PCB prototype,small volum, middle and large volume are accepted. no MOQ request for new boards. for repeat order, just meet 3sq.m.





Key Specifications of High Voltage  PCB:



Production Types:  Rigid PCB

Layer :

 2 Layers
Base Material : KB FR4
Copper Thickness : Hoz
Board Thickness :  1.30mm
Min. Finish Hole Size :  8.3 mil
Min. Line Width :  5 mil
Min. Line Spacing :  5 mil
Surface Finishing : Immerison tin
Drilling hole tolerance: +/-3 mil    (  0.075mm )
Min Outline tolerance : +/-4 mil    (  0.10mm )
Working panel size :  max:1200mmX600mm (47'' X24'')
Outline profile: Punching, Routing , CNC routing + V-cut
Solder mask : LPI Solder mask, Peelable mask
Solder Mask Color : Blue, black,yellow, matte green
Certificate : UL, CQC, TS16949, ISO14000, ROHS
Silkscreen color : White
Twist and Bow :  no more than 0.75 %





PCB Flow Chart.pdf







Rigid PCB Technical Capability:



 Items                                      Technical Capability
Layers 1-28 layers Min. line width/space 4mil

Max.board size (single&doule

sided)

600*1200mm Min.annular ring width: vias 3mil
Surface finish

HAL lead free,gold flash

Immersion silver,Immersion gold ,Immersion Sn,

hard gold,OSP,ect

Min.board thickness(multilayer) 4layers:0.4mm;
6layers:0.6mm;
8layers:1.0mm;
10layers:1.20mm
Board materials

FR-4; high Tg; high CTI; halogen free; high frequency(rogers,taconic,

PTFE,nelcon,

ISOLA,polyclad 370 HR); heavy copper,

Metal base clade laminate

Plating thickness (Technique:

Immersion Ni/Au)

Plating type: Imm Ni, Min./Max thickness:100/150U'' Plating type: Imm Au, Min./Max thickness:2/4U''
Impedance control ± 10%

Distance between

line to board edge

Outline: 0.2mm

V-CUT: 0.4mm

Base copper thickness(Inner

and outer layer)

Min. thickness: 0.5 OZ Max.thickness: 6OZ Min.hole size(board thickness ≥2mm) Aspect ratio≤16
Finished copper thickness Outer layers:
Min.thickness 1 OZ,
Max.thickness 10 OZ
Inner layers:
Min.thickness :0.5OZ,
Max.thickness : 6 OZ
Max.board thickness(single&doule sided) 3.20mm



Products Application:



Our products are widely used in meter, medical, solar energy, mobile, communication, industrial control, power electronics,security, consum electronics, computer, automotive, aerospace, military and so on.
