Finish Thickness: | 1.6±10%mm | Minimum Via Dia: | 0.15mm |
---|---|---|---|
Surface Finish: | Lead Free HAL | Dielectric Constant: | 4.0 |
Application: | Electronic Device | Name: | PWB Circuit Board |
Layer: | 8layer | Cooper Thickness: | 2oz |
Min Drill Holes: | 0.2mm | ||
High Light: | 3oz PWB Circuit Board,KB FR4 PWB Circuit Board,lead free HAL PWB Circuit Board |
8 Layer Immersion Gold KB FR4 High TG 3oz PWB Circuit Board
KBFR4 High TG PWB Circuit Board with immersion gold and black Solder Mask
Production description :
this board is 8layer with 3oz copper thickness. it is used on electronic equipment. PCB prototype,small volum, middle and large volume are accepted. no MOQ request for new boards. for repeat order, just meet 3sq.m.
Material : | FR4 8 layer |
Finish thickness : |
1.60 ±10%mm |
Minimum width/spacing : |
0.15mm / 0.15mm |
Minimum via dia : |
0.2mm |
Surface finish : |
ENIG |
Immpedance : |
100 ohm |
Solder mask : |
Dark Green |
Legends : | White |
Certification : |
ISO UL ROHS SGS |
Company type: | Manufacturer/ Factory |
Min. Finish Hole Size : | 8 mil (0.10mm) |
Min. Line Width : | 4mil |
Min. Line Spacing : | 4mil |
Min Outline tolerance : | +/-4 mil ( 0.10mm ) |
Twist and Bow : | no more than 0.75% |
Here is our PCB order capability
Applications:
Bonus Systems Class II Tabs-video Devices, Amplifier, Main Control Board, Power Supply,Coinless Systems, Progressive Jackpot Equipment, Slot Devices, Slot Systems, Themed Devices, Video Devices, Video Poker Devices, Amusement Equipment, Simulators, Virtual Reality, Entertainment Admissions Systems, Laser Projection Equipment, Lighting Equipment ect.
FAQ :
1. What kinds of boards can ACCPCB process?
Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.
2. What data are needed for PCB production?
PCB Gerber files with RS-274-X format.
3. What’s the typical process flow for multi-layer PCB?
Material cutting → Inner dry film → inner etching → Inner AOI → Multi-bond→ Layer stack up Pressing → Drilling → PTH → Panel Plating → Outer Dry Film → Pattern Plating → Outer etching → Outer AOI → Solder Mask → Component Mark → Surface finish → Routing → E/T → Visual Inspection.
5. How many types of surface finish ACCPCB can do?
O-the leader has the full series of surface finish, such as: ENIG, OSP, LF-HASL, gold plating (soft/hard), immersion silver, Tin, silver plating, immersion tin plating, carbon ink and etc. .. OSP, ENIG, OSP + ENIG commonly used on the HDI, we usually recommend that you use a client or OSP OSP + ENIG if BGA PAD size less than 0.3 mm.
6. How to you make the impedance calculation?
The impedance control system is done using some test coupons, the SI6000 soft and the CITS 500s equipment
