| Place of Origin: | China |
| Brand Name: | ACCPCB |
| Certification: | ISO,UL,SGS,TS16949,ROHS |
| Model Number: | P121702 |
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Vacuum Packing With Desiccant |
| Delivery Time: | 6-10days |
| Payment Terms: | T/T / Western Union / Paypal |
| Supply Ability: | 35,000SQ.M/Per Month |
| Finish Thickness: | 1.3±10%mm | Minimum Via Dia: | 0.15mm |
|---|---|---|---|
| Surface Finish: | Lead Free HAL | Dielectric Constant: | 4.0 |
| Application: | Electronic Device | Name: | PWB Circuit Board |
| High Light: | HASL PWB Circuit Board,FR4 High TG PWB Circuit Board,FR4 6 Layer PWB Circuit Board |
||
Dark Green Solder Mask FR4 High TG HASL PWB Circuit Board
KB FR4 TG PWB Circuit Board with dark green solder mask for circuit test
Production description :
this board is 6layer PCB with ENIG. PCB prototype,samll volum, middle and large volume are accepted. no MOQ request for new boards. ALL PCB board are met UL, ISO900,TS16949, ROHS etc.
| Material : | FR4 6 layer |
| Finish thickness : |
1.00 ±10%mm |
| Minimum width/spacing : |
0.15mm / 0.15mm |
| Minimum via dia : |
0.2mm |
| Surface finish : |
ENIG |
| Immpedance : |
100 ohm |
| Solder mask : |
Dark Green |
| Legends : | White |
| Certification : |
ISO UL ROHS SGS |
| Company type: | Manufacturer/ Factory |
Here is our PCB order capability:
Applications:
Bonus Systems Class II Tabs-video Devices, Amplifier, Main Control Board, Power Supply,Coinless Systems, Progressive Jackpot Equipment, Slot Devices, Slot Systems, Themed Devices, Video Devices, Video Poker Devices, Amusement Equipment, Simulators, Virtual Reality, Entertainment Admissions Systems, Laser Projection Equipment, Lighting Equipment ect.
FOB Port : Hong Kong / Shenzhen
Lead Time : 6-10 days
HTS Code : 8534.00.10
Dimensions Per Carton : 37X27X22 cm
Weight Per Carton : 20 Kilograms
FAQ :
1. What kinds of boards can ACCPCB process?
Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.
2. What data are needed for PCB production?
PCB Gerber files with RS-274-X format.
3. How many types of surface finish ACCPCB can do?
the leader has the full series of surface finish, such as: ENIG, OSP, LF-HASL, gold plating (soft/hard), immersion silver, Tin, silver plating, immersion tin plating, carbon ink and etc. .. OSP, ENIG, OSP + ENIG commonly used on the HDI, we usually recommend that you use a client or OSP OSP + ENIG if BGA PAD size less than 0.3 mm.
4. How do ACCPCB ensure quality?
Our high quality standard is achieved with the following.
1.1 The process is strictly controlled under ISO 9001:2008 standards.
1.2 Extensive use of software in managing the production process
1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
1.4.Dedicated quality assurance team with failure case analysis process
5. What are the main factors which will affect the price of PCB?
Material;
Surface finish;
Board thickness, Copper thickness;
Technology difficulty;
Different quality criteria;
PCB characteristics;
Payment terms;
6. How to you make the impedance calculation?
The impedance control system is done using some test coupons, the SI6000 soft and the CITS 500s equipment
