| Place of Origin: | China |
| Brand Name: | ACCPCB |
| Certification: | ISO, UL, SGS,TS16949 |
| Model Number: | P1032 |
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Vacuum packing with desiccant |
| Delivery Time: | 10-15days |
| Payment Terms: | L/C, T/T, Western Union，Paypal |
| Supply Ability: | 30000SQ.M/Per Month |
| Material: | KBFR4 | Application: | Battery Protection Board |
|---|---|---|---|
| Cooper Thickness: | 1.5 Oz Each Layer | Board Thickness: | 2.0mm |
| Surface Finish: | Immersion Gold | Feature: | Rigid Circuit Boards |
| High Light: | copper base pcb,copper clad circuit board |
||
ITEQ FR4 material Heavy Copper PCB Fabrication Customizable Design for battery
Production description :
this board is 4layer with 2/3 oz copper thickness. all of these boards are met UL,TS16949, ISO9001 etc. we can accept any quantity board such as PCB prototype,samll volum, middle and large volume . no MOQ request for new order.
| Layer : | 4 Layers |
| Base Material : | iteq fr4 |
| Copper Thickness : | 3 / 2 / 2 / 3 oz |
| Board Thickness : | 2.30mm |
| Min. Hole Size : | 8 mil, 0.2mm |
| Min. Line Width : | 4 / 4 mil |
| Min. Line Spacing : | 4 / 4 mil |
| Surface Finishing : | Immersion gold |
| Solder Mask Color : | green |
| Certificate : | UL, CQC, TS16949, ISO14000, ROHS |
| Silkscreen color : | White |
| Outline : | Routing |
| HS Code : | 85340010 |
| Outline profile: | CNC routing, punching |
| outline tolerance: | 0.127mm |
Quality Goal:
| Category | Performance indicator | Quality Goal |
|
Delivery |
Customer service rate | 99.9% |
| Semi Finished product | Process inspection pass rate | 100% |
| Finished product | FQA Rebate rate | 0.1% |
| Scrapped | 1L scrap rate | 0.5% |
| 2L scrap rate | 1% | |
| Multi Layer scrap rate | 2% | |
| Customers | Customer complaint rate | 0.8% |
| Customer return rate | 0.5% | |
| Customer satisfaction | 99% |
Quality assurance :
Every production process has a special person to test to ensure quality, AOI, E-testing, Flying Probe Test.
Have professional engineers to check the quality
All products have passed CE, FCC, ROHS and other certifications
Product Application Field :
FAQ
1. How do ACCPCB ensure quality?
Our high quality standard is achieved with the following.
1.1 The process is strictly controlled under ISO 9001:2008 standards.
1.2 Extensive use of software in managing the production process
1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
1.4.Dedicated quality assurance team with failure case analysis process
2. What kinds of boards can ACCPCB process?
Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.
3. What data are needed for PCB production?
PCB Gerber files with RS-274-X format.
